Chapter 6: Console Configuration
The Patch Direct Display
258/ 526 2.0 Eclipse User Guide
Over Ram for Direct I/O
The OVERRAM buttons on the right of the display allow you to
select a single crosspoint, or an area of crosspoints, so that
patching and IO parameters can be written into other Pages in
RAM. This allows you to modify settings for the Pages which
will play out during a show.
For example, if you have a talkback mic which is routed directly
to a DioCore output (for talkback to the monitor mixer), and you
adjust its patching or IO settings, then you can use the
OVERRAM function to write these changes into the other
Pages of the show.
Note that the principles of operation are identical to those of the
main Over Ram display, see Page 399. However, the Over
Ram display acts only on the selected channel(s). OVERRAM
from the PATCH DIRECT grid acts on the selected source and
destination, enabling you to Over Ram signals which are not
connected to a Fader strip or Smart Panel controller.
Note that parameters are updated according to their absolute
values; you cannot trim an existing value.
