Chapter 6: Console Configuration
Internal Effects (the FM-8VB Card)
Eclipse User Guide 2.0 307/ 526
3. Select a bay configuration and Open.
The plug-in assignments and effects parameters are loaded to
your selected channel.
Note that the complete bay configuration can only be loaded if
there is enough DSP resource left on the FM8-VB card to
support the stored settings.
For example, if you have already used your complement of four
JustVerb plug-ins, then the bay LOAD may fail. An error pop-
up appears if this occurs. To successfully load the bay
configuration you will need to remove a JustVerb resource from
another channel on the FM8-VB card.
Mono/Stereo Configuration
1. Click on the MONO or STEREO button to change the
mono/stereo configuration of the effects bay.
This is the same as the St. button within the FM Configuration
window of the PATCH displays.
