Appendices
Appendix A: The Standard Template
Eclipse User Guide 2.0 511/ 526
Control Surface Layout
The Templ1 File loads the following Personal Console Builder
assignments to the Fader Strips and Smart Panel Controllers:
Fader Strips 1-48:
Fader Strip Channel Type Label Mono/Stereo DSP
1-32
Input Channels
(DioCore Mic/Line inputs 1-32)
Di01
Di02..
Mono
Input Channel Processing
33
Spare
34-39
VCA masters (VCA 1 to 6) VCA1.. n/a
n/a
40
Spare
41-44
Aux 1-4 (DioCore UM-8PO 1-8) AUX1...
Au L/R
Stereo
Output Processing (UM8)
47
Master Left & Right
(Console UM-8PO card 1&2)
MasL/R Stereo
Output Processing (UM8)
Smart Panel Controllers 1-48:
Smart Panel Channel Type Label Mono/Stereo DSP
A (FX)
Upper
Input Channels (FX Returns 1-4) FX1L/R.. Linked Mono Input Channel Processing
A (FX)
Lower
Auxes (FX Sends 1-4) FX1.. Mono
Internal Effects
B (IN)
Lower
Input Channels
(Console Mic/Line inputs 1-8)
Li01.. Mono Input Channel Processing
C (VCA)
VCA masters (VCAs 1-12) VCA1.. n/a
n/a
D (Mtx)
Matrix masters
(Console UM-8PO Out 3-14)
Mtx1.. Mono
Output Processing (UM8)
