Related Topics show bgp ipv6 inconsistent-as•
• show ip bgp inconsistent-as
Monitoring BGP Neighbors
Purpose Display information about BGP neighbors.
The show ip bgp neighbors and show bgp ipv6 neighbors commands display similar
information.
Action To display information about BGP neighbors:
• host1#show ip bgp neighbors
BGP neighbor ID 10.2.1.48, remote AS 11488 (external peer)
Remote router ID is 172.31.1.48, negotiated BGP version is 4
Administrative status is Start, connection state is Established
Reason for last reset was tcp connection error
TCP error code 60 (Connection timed out)
Connection has been established 1 time, up for 0 17:42:31
Options:
Default originate is disabled
EBGP multi-hop is enabled
IBGP single-hop is disabled
Next hop self is disabled
seconds
Policy:
Neighbor weight is 100
Timers:
Connect retry interval is 120 seconds
Minimum route advertisement interval is 30 seconds
Minimum AS origination interval is 10 seconds
Configured keep-alive interval is 30 seconds, negotiated 30
seconds
Configured hold time is 90 seconds, negotiated 90
TCP connection:
Local IP address is 192.168.1.218, local port is 1024
Remote IP address is 10.2.1.48, remote port is 179
Statistics:
Total of 4100 messages sent, 44913 messages received
2053 update messages sent, 42785 update messages received
0 00:00:17 since last update message was received
• Fields relevant to multiprotocol extensions:
Multi-protocol extensions negotiation:
ip-v4 unicast: sent, received, used
ip-v6 unicast-labeled: sent, received, used
• For the graceful restart capability, additional information is presented.
Copyright © 2010, Juniper Networks, Inc.180
JunosE 11.2.x BGP and MPLS Configuration Guide
