This excerpt from the command output shows the label information displayed when a
circuit is up
host1#show mpls l2transport interface
...
Out Label 49 on tun mpls:lsp-de090100-24-37
0 pkts, 0 hcPkts, 0 octets
0 hcOctets, 0 errors, 0 discardPkts
queue 0: traffic class best-effort, bound to atm-vc ATM1/0.1
Queue length 0 bytes
Forwarded packets 0, bytes 0
Dropped committed packets 0, bytes 0
Dropped conformed packets 0, bytes 0
Dropped exceeded packets 0, bytes 0
...
To display summary information about MPLS shim interfaces:
host1#show mpls interface shim brief
Remote-PE Virtual Load
or Circuit Balancing Admin Oper
Interface LSP-name ID Group state state
----------------- --------- ------- --------- ------- -----
FastEthernet2/0.1 222.9.1.3 200001 - enabled up
FastEthernet2/0.2 222.9.1.3 200002 - enabled up
Meaning Table 107 on page 567 lists the show mpls interface and show mpls l2transport interface
command output fields
Table 107: show mpls interface and show mpls l2transport interface
Output Fields
Field DescriptionField Name
Interface specifierMPLS shim interface
Address of the remote PE router for the layer 2 circuitRemote PE address
VC ID number for the interfaceVirtual circuit ID
Group ID number for the interfaceGroup ID
Configuration of the control wordControl word
Statement regarding configuration of sequence numberSequence number
Configuration of relay formatRelay format
Starting and ending (inclusive) virtual path identifiers and virtual
circuit identifiers of the reserved VC range and whether the range
specification is activated on the line module for transportation of
ATM cells that belong to multiple VCs over a single pseudowire.
ATM VPI/VCI range
Concatenation of multiple ATM cells to be sent in a single
MPLS-labeled packet for an ATM port, enabled or disabled.
ATM cell aggregation
567Copyright © 2010, Juniper Networks, Inc.
Chapter 10: Monitoring Layer 2 Services over MPLS
