Site Range 10
Sites:
Site Name westford Site Id 1
Multihomed priority 200
Route Targets:
Route Target: RT:100:2 both
Admin Oper
Interface Local-Site-Id Remote-Site-Id state state
---------- ------------- -------------- ------- -----
ATM2/0.100 1 2 enabled up
ATM2/0.12 1 3 enabled up
Connections status code:
UP = Operational
SC = Local and Remote Site Identifier Collision
EM = Encapsulation Mismatch
OR = Out of Range
DN = VC Down because Remote PE Unreachable
LD = Local Site Down
RD = Remote Site Down
AS = Max BGP AS path length exceeded
OL = No Out Label
CM = Control Word Mismatch
LN = Local Site not Designated
RN = Remote Site not Designated
Remote MPLS Up-down
Site State PE In-label Out-label NH Idx Time
---- ----- ------- -------- --------- -------- -----------
2 UP 2.2.2.2 17 801024 00000014 1d 08:45:34
3 UP 2.2.2.2 18 801028 00000014 1d 08:45:34
Meaning Table 139 on page 672 lists the show l2vpn connections command output fields.
Table 139: show l2vpn connections Output Fields
Field DescriptionField Name
Name of the VPWS instanceL2VPN
Encapsulation type configured for the VPWS instanceEncapsulation Type
Local preference for control word, preferred or not preferredUse of control word
Local preference for sequence number, send or don’t sendsequence numbers
Route distinguisher configured for the VPWS instanceRoute Distinguisher
Maximum number of customer sites allowed in the VPWS instanceSite Range
Site name and site ID for each customer site in the VPWS instanceSites
Priority of the VPWS instance to serve as the backup PE router for
the CE device in the event of a network failure in the multihomed
configuration; indicates also that the site is multihomed
Multihomed priority
Route targets configured for the VPWS instanceRoute Targets
Layer 2 interface that is a member of the VPWS instanceInterface
