Related Topics For more information about using the traceroute command, see Reachability Commands
in the JunosE IP, IPv6, and IGP Configuration Guide,
•
• traceroute
Monitoring ATM VCs and VPI/VCI Ranges Used for MPLS
Purpose Display information about ATM VCs used as MPLS LSPs and VPI-VCI ranges reserved
for MPLS when you use the interface label space for MPLS labels.
Action To display all VCs and reserved VC ranges on the router:
host1#show atm vc
Cate Rx/Tx Rx/Tx Rx/Tx Sta
Interface VPI VCI VCD Type Encap gory Peak Avg Burst tus
------------ --- ---- ---- ---- ----- ---- ----- ----- ----- ---
ATM 3/0.2 0 101 4375 PVC AUTO CBR 1000 0 0 UP
ATM 3/0.3 0 102 4376 PVC AUTO CBR 1000 0 0 DOWN
...
ATM 3/0.8099 1 8099 8099 PVC SNAP UBR 0 0 0 UP
ATM 3/0.8100 1 8100 8100 PVC SNAP UBR 0 0 0 DOWN
8000 circuit(s) found
Reserved VCC ranges:
Start Start End End
Interface VPI VCI VPI VCI
--------- ----- ----- --- ---
ATM 2/0 2 100 2 102
ATM 2/0 3 300 3 303
2 reservation(s) found
To display a summary of all reserved VC ranges on the router, including those reserved
for MPLS use:
host1#show atm vc reserved
Reserved VCC ranges:
Start Start End End
Interface VPI VCI VPI VCI
--------- ----- ----- --- ---
ATM 2/0 2 100 2 102
ATM 2/0 3 300 3 303
2 reservation(s) found
Meaning Table 60 on page 326 lists the show atm vc command output fields.
Table 60: show atm vc Output Fields
Field DescriptionField Name
Interface type and numberInterface
Virtual path identifierVPI
Virtual channel identifierVCI
Virtual circuit descriptorVCD
Type of circuit: PVCType
Copyright © 2010, Juniper Networks, Inc.326
JunosE 11.2.x BGP and MPLS Configuration Guide
