You configure a shared secret (password) on potential LDP peers. Any given pair of peers

must share the same password. When a peer sends a TCP segment to an LSR, it uses

the password and the segment to compute an MD5 digest that it sends along with the

segment.

When the LSR receives the segment, the LSR calculates its own version of the digest

using its instance of the password and the segment. The LSR validates the segment if

the local digest matches the received digest. If the comparison fails—for example, if the

password is not configured the same on both peers—the LSR drops the segment and

does not send a response to the peer.

You can optionally enable a strict authentication mode that allows only peers configured

with passwords to establish sessions. In this mode, LDP hello messages from peers that

have no password are ignored. If you do not configure strict authentication, then peers

that do not have configured passwords can establish connections with each other.

If you configure LDP MD5 authentication or change the authentication password for a

peer while it is in an established LDP session, MPLS restarts that session.

To configure LDP MD5 authentication:

1. Set the password for an LDP peer.

host1(config)#mpls ldp neighbor 10.3.5.1 password rop23ers

2. (Optional) Set strict LDP authentication mode so that only peers with passwords

can establish LDP sessions.

host1(config)#mpls ldp strict-security

Related Topics Basic MPLS Configuration Tasks on page 276•

• Additional LDP Configuration Tasks on page 288

• mpls ldp neighbor password

• mpls ldp strict-security

Controlling LDP Label Distribution

By default, LDP advertises label mappings for all IGP prefixes to all LDP peers. In this

case, mappings are not advertised for interface addresses. You can alternatively specify

that LDP labels be distributed for a particular interface itself, in addition to the subnet

that the interface is on. This behavior enables LSPs to be set up to the LSR configured

with the interface address.

When the LSR learns an IGP route and tries to decide whether to advertise a label for the

destination to a particular LDP neighbor, it attempts to match the destination against a

route access list specified by the mpls ldp advertise-labels command, in the order in

which the commands were issued. The first match determines the action taken, and no

further matching is attempted for that destination. If the destination matches, labels are

advertised to peers subject to any specified neighbor address list. If either access list is

not matched, the labels are not advertised.
