Monitoring VPLS Configuration and Statistics for a Specific VPLS Instance
Purpose Display configuration and statistics information for the specified VPLS instance.
Action To display configuration information for a specified VPLS (vplsA):
host1#show bridge vplsA
BridgeGroup: vplsA(vpls)
Bridge Mode: default
Aging Time: 300 secs
Learning: Enabled
Max Learn: Unlimited
Link Status Snmp Traps: Disabled
Subscriber Policy: default Subscriber
Port Count: 2
Interface Count: 1
Transport Virtual Rtr: default
Route Distinguisher: 1.1.1.1:10
SiteName: boston
SiteId: 1
Multi-homed: Yes
Site-Priority: 45
SiteRange: 10
VPLS Route Targets
Route Target: RT:100:1 (both)
Route Target: RT:100:2 (both)
Flood Next Hop: Index 1048577
Use the all keyword to display address table and statistics information for all network
interfaces associated with the VPLS instance.
Meaning Table 118 on page 613 lists the show bridge command output fields.
Table 118: show bridge Output Fields
Field DescriptionField Name
Name of the VPLS instance for which information is displayedBridgeGroup
Bridging capability currently enabled; for a VPLS instance, this field
always displays default
Bridge Mode
Length of time, in seconds, that a MAC address entry can remain in
the forwarding table before expiring
Aging Time
Whether acquisition of dynamically learned MAC addresses is
enabled or disabled
Learning
Maximum number of dynamic MAC addresses that the VPLS
instance can learn
Max Learn
Whether SNMP link status processing is enabled or disabledLink Status Snmp Traps
Name of the subscriber policy currently in effectSubscriber Policy
613Copyright © 2010, Juniper Networks, Inc.
Chapter 13: Monitoring VPLS
