Administrative status is Start
EBGP multi-hop is disabled
IBGP single-hop is disabled
BFD is enabled:
Single-hop IPv4 BFD session
Minimum transmit interval is 300 ms
Minimum receive interval is 300 ms
Multiplier is 3
Maximum update message size is 1024 octets
Neighbor weight is 0
Connect retry interval is 10 seconds initially
Configured keep-alive interval is 30 seconds
Configured hold time is 90 seconds
Minimum route advertisement interval is 30 seconds
Minimum AS origination interval is 10 seconds
Graceful restart negotiation:
Restart time is 120 seconds
Stale paths time is 360 seconds
Configuration for address family ipv4:unicast
RIB-out is disabled
Default originate is disabled
Next hop self is disabled
Next hop unchanged is disabled
Don't send communities
Inbound soft reconfiguration is disabled
Private AS number stripping is disabled
Override site AS with provider AS is disabled
No loops in the received AS-path are allowed
Members: 10.2.2.2 10.3.3.3
• Fields relevant to conditional advertisement:
Advertise-map is advertisetoR1
Condition-map: trigger1
Sequence: 5
Status: Withdraw
Advertise-map is alternatetoR1
Condition-map: trigger2
Sequence: 10
Status: Advertise
Meaning Table 44 on page 194 lists the show ip bgp peer-group command output fields.
Table 44: show ip bgp peer-group Output Fields
Field DescriptionField Name
Name of a BGP peer groupBGP peer group
Remote AS of the BGP neighborremote AS
Local autonomous system numberlocal AS
Desired state of the peer connectionAdministrative status
Status of EBGP multihop for the peer group (enabled or disabled)EBGP multi-hop
Status of IBGP single hop for the peer group (enabled or disabled)IBGP single-hop
Copyright © 2010, Juniper Networks, Inc.194
JunosE 11.2.x BGP and MPLS Configuration Guide
