Table 84: show mpls rsvp counters Output Fields (continued)
Field DescriptionField Name
Number of resvconf messages received on the interfaceAck Conf Rcvd
Number of nack objects sent on the interfaceNack Objects Sent
Number of nack objects received on the interfaceNack Objects Rcvd
Number of message bundles sent on the interfaceMsg Bundles Objects Sent
Number of message bundles received on the interfaceMsg Bundles Rcvd
Number of error messages received on the interfaceError Msgs Rcvd
Number of misordered messages received on the interfaceMisordered Messages
Number of failures to successfully send messages on the interfaceSend Failures
Number of locally triggered path messagesPath Triggers
Number of locally triggered resv messagesResv Triggers
RSVP control packets that are forwarded through the routerForwarded Pkts
Number of hello messages sentHello Sent
Number of hello messages receivedHello Rcvd
Number of acknowledgments sent in response to hello requests
received
Hello Ack Sent
Number of acknowledgments received in response to hello requests
sent
Hello Ack Rcvd
Number of hello messages discardedHello Discarded
Number of hello ack messages discardedHello Ack Discarded
Number of hello messages suppressed; message generation is
suppressed when a hello request object is received from the
destination node within the hello interval
Hello Suppressed
Related Topics show mpls rsvp counters•
Monitoring RSVP-TE Graceful Restart
Purpose Display information about the state of RSVP-TE graceful restart.
365Copyright © 2010, Juniper Networks, Inc.
Chapter 5: Monitoring MPLS
