Juniper JUNOSE 11.2.X BGP AND MPLS User Manual

Monitoring Load-Balanced Martini Circuits
Purpose Display information about load-balanced Martini circuits
Action To display brief information about load-balanced Martini circuits:
host1#show mpls l2transport load-balancing-group member-circuits brief
4 member ports:
fastEthernet 2/0 down
fastEthernet 3/0 30 member circuits
fastEthernet 4/0 30 member circuits
fastEthernet 5/0 30 member circuits
90 member circuits
To display detailed information about load-balanced Martini circuits:
host1#show mpls l2transport load-balancing-group 100 member-circuits
routed to 10.9.1.3 on base LSP tun mpls:lsp-de090103-32-3e
load-balancing-group 100
Martini group-id 2 vc-id 200002 mtu 1500
State UP
In Label 57 on stack
0 pkts, 0 hcPkts, 0 octets
0 hcOctets, 0 errors, 0 discardPkts
Out Label 59 on tun mpls:lsp-de090103-32-3e
0 pkts, 0 hcPkts, 0 octets
0 hcOctets, 0 errors, 0 discardPkts
queue 0: traffic class best-effort, bound to atm-vc ATM6/0.1
Queue length 0 bytes
Forwarded packets 0, bytes 0
Dropped committed packets 0, bytes 0
Dropped conformed packets 0, bytes 0
Dropped exceeded packets 0, bytes 0
Member Interfaces
Interface fastEthernet 2/0.2 active
Incoming Traffic Statistics
0 pkts, 0 hcPkts, 0 octets
0 hcOctets, 0 errors, 0 discardPkts
Outgoing Traffic Statistics
0 pkts, 0 hcPkts, 0 octets
0 hcOctets, 0 errors, 0 discardPkts
Interface fastEthernet 3/0.2
Incoming Traffic Statistics
0 pkts, 0 hcPkts, 0 octets
0 hcOctets, 0 errors, 0 discardPkts
Outgoing Traffic Statistics
0 pkts, 0 hcPkts, 0 octets
0 hcOctets, 0 errors, 0 discardPkts
NOTE: For a simpler view, the show mpls l2transport interface command displays only
the currently active VLAN or S-VLAN subinterface. Because load-balanced circuits are
configured on subinterfaces on multiple ports, only one of which is active at a given
time, this command does not give a complete picture of the configuration.
Meaning Table 99 on page 504 lists the show mpls l2transport load-balancing-group command
output fields.
503Copyright © 2010, Juniper Networks, Inc.
Chapter 7: Monitoring BGP/MPLS VPNs
