Table 96: show ip protocols Output Fields (continued)
Field DescriptionField Name
The network for which BGP is currently injecting routesRouting for Networks
IS-IS
6-byte value of the routerSystem Id
Routing type of the router: Level 1, Level 2IS-Type
Administrative distance for IS-IS learned routesDistance
Aggregate addresses defined in the routing table for multiple groups
of addresses at a given level or routes learned from other routing
protocols
Address Summarization
Network for which IS-IS is currently injecting routesRouting for Networks
OSPF
OSPF process ID for the routerRouter ID
Administrative distance for OSPF learned routesDistance
Protocol to which OSPF is redistributing routesRedistributing
Aggregate addresses defined in the routing table for multiple groups
of addresses at a given level or routes learned form other routing
protocols
Address Summarization
Network for which OSPF is currently injecting routesRouting for Networks
RIP
RIP protocol state. Enable means it is allowed to send and receive
updates. Disable means that it may be configured but it is not
allowed to run yet.
Router Administrative
State
RIP versions allowed for sending and receiving RIP updates. The
system version is currently set to RIP1, which sends RIP version 1 but
will receive version 1 or 2. If the version is set to RIP2, the system will
send and receive version 2 only. The default is configured for RIP1.
System Version
Current setting of the update timer (in seconds)Update interval
Current setting of the invalid timer (in seconds)Invalid after
Current setting of the hold down timer (in seconds)hold down time
Current setting of the flush timer (in seconds)flushed interval
Access list applied to outgoing RIP route updatesFilter applied to outgoing
route update
495Copyright © 2010, Juniper Networks, Inc.
Chapter 7: Monitoring BGP/MPLS VPNs
