Keysight B2961A/B2962A SCPI Command Reference, Edition 6 2- 23
Subsystem Command Summary
Setting Source Output and Measurement
[:SOUR[c]]:PULS:WIDT width
[:SOUR[c]]:PULS:WIDT? [DEFault|
MINimum|MAXimum]
Sets the pulse width for the specified
channel. The pulse width is the time from
starting the pulse peak output (or starting
the pulse level transition) to the end of the
pulse peak output.See Figures
2-6 and
2-3.
width=DEFault|MINimum|MAXimum|
5E-5 to 100000 seconds, in 1E-6
resolution
Minimum time for the pulse base output
is also 50 μs. And the minimum pulse
period is 100 μs.
5E-5
seconds
[:SOUR[c]]:SWE:DIR direction
[:SOUR[c]]:SWE:DIR?
Sets the sweep direction, UP or DOWN,
for the specified channel.
direction=DOWN|UP
UP
[:SOUR[c]]:SWE:POIN points
[:SOUR[c]]:SWE:POIN? DEFault|
MINimum|MAXimum
Sets the number of sweep steps for the
specified channel. This command setting
is effective for both current sweep and
voltage sweep.
points=DEFault|MINimum|MAXimum|
1
to 100000
The points value can be expressed by the
following formula, using the step value
set by the
[:SOUR[c]]:<CURR|VOLT>:STEP
command and the span value set by the
[:SOUR[c]]:<CURR|VOLT>:SPAN
command.
points = span/step + 1 (where step is not
0)
points=1 sets step=0.
1
[:SOUR[c]]:SWE:RANG mode
[:SOUR[c]]:SWE:RANG?
Selects the output ranging mode of the
sweep output for the specified channel.
mode=BEST|FIXed|AUTO
BEST
Command Summary Reset setting
