Keysight B2961A/B2962A SCPI Command Reference, Edition 6 2- 33
Subsystem Command Summary
Setting Source Output and Measurement
Table 2-3 OUTPut Subsystem
Command Summary Reset setting
:OUTP[c]:FILT:EXT:TYPE type
:OUTP[c]:FILT:EXT:TYPE?
Sets the external filter type.
type=HCULNF|ULNF|LNF
ULNF
:OUTP[c]:FILT:EXT:STAT type
:OUTP[c]:FILT:EXT:STAT?
Enables or disables the external filter
status.
OFF
:OUTP[c]:FILT[:LPAS]:AUTO mode
:OUTP[c]:FILT[:LPAS]:AUTO?
Enables or disables the automatic filter
function.
mode=1|ON|0|OFF
OFF
:OUTP[c]:FILT[:LPAS]:FREQ freq
:OUTP[c]:FILT[:LPAS]:FREQ? [DEFa
ult|MINimum|MAXimum]
Sets the cutoff frequency of the output
filter. This command setting is ignored if
the automatic filter function is enabled by
the :OUTP:FILT:AUTO command.
freq=MINimum|MAXimum|DEFault|
3.18309886 Hz to 31.8309886 kHz
freq = 1/(2 × π × Tconst)
MIN
:OUTP[c]:FILT[:LPAS][:STAT] mode
:OUTP[c]:FILT[:LPAS][:STAT]?
Enables or disables the output filter.
mode=1|ON|0|OFF
ON
:OUTP[c]:FILT[:LPAS]:TCON Tconst
:OUTP[c]:FILT[:LPAS]:TCON? [DEFa
ult|MINimum|MAXimum]
Sets the time constant instead of setting
the cutoff frequency of the output filter.
This command setting is ignored if the
automatic filter function is enabled by the
:OUTP[c]:FILT:AUTO command.
Tconst=MINimum|MAXimum|DEFault|
5 μs to 50 ms
Tconst = 1/(2 × π × freq)
MIN
:OUTP[c]:HCAP[:STAT] mode
:OUTP[c]:HCAP[:STAT]?
Enables or disables the high capacitance
mode.
mode=1|ON|0|OFF
OFF
:OUTP[c]:LOW low_state
:OUTP[c]:LOW?
Selects the state of the low terminal.
low_state=FLOat|GROund
GRO
