Keysight B2961A/B2962A SCPI Command Reference, Edition 6 2- 65
Subsystem Command Summary
Using Advanced Functions
Using Advanced Functions
Table 2-17 HCOPy Subsystem
Table 2-18 DISPlay Subsystem
Command Summary Reset setting
:HCOP:SDUM:DATA?
Returns the data of the front panel screen
image. The response is a definite length
arbitrary binary block.
:HCOP:SDUM:FORM format
:HCOP:SDUM:FORM?
Sets the format of the image data.
format=JPG|BMP|PNG|WMF
JPG
Command Summary Reset setting
:DISP:CSET color
:DISP:CSET?
Selects the color set of the front panel
display.
color=1 (default color set)|2 (alternative
color set)
:DISP:ENAB mode
:DISP:ENAB?
Enables or disables the front panel
display under remote operation.
mode=1|ON|0|OFF
:DISP:VIEW mode
:DISP:VIEW?
Sets the display mode, single 1, single 2,
dual, or graph.
mode=SINGle1|SINGle2|DUAL|GRAPh
SING1 for
1-ch models
DUAL for
2-ch models
:DISP[:WIND[d]]:DATA?
Returns the data displayed on the front
panel display.
