Keysight B2961A/B2962A SCPI Command Reference, Edition 6 2- 39
Subsystem Command Summary
Setting Source Output and Measurement
Measurement Ranges
Table 2-7 Voltage Measurement Range
Table 2-8 Current Measurement Range
Range value Voltage measurement value Resolution
0.2 V 0 ≤ |V| ≤ 0.212 V 10 μV
2 V 0 ≤ |V| ≤ 2.12 V 100 μV
20 V 0 ≤ |V| ≤ 21.2 V 1 mV
200 V 0 ≤ |V| ≤ 212 V 10 mV
Range value Current measurement value Resolution
10 nA 0 ≤ |I| ≤ 10.6 nA 1 pA
100 nA 0 ≤ |I| ≤ 106 nA 10 pA
1 μA 0 ≤ |I| ≤ 1.06 μA 100 pA
10 μA 0 ≤ |I| ≤ 10.6 μA 1 nA
100 μA 0 ≤ |I| ≤ 106 μA 10 nA
1 mA 0 ≤ |I| ≤ 1.06 mA 100 nA
10 mA 0 ≤ |I| ≤ 10.6 mA 1 μA
100 mA 0 ≤ |I| ≤ 106 mA 10 μA
1 A 0 ≤ |I| ≤ 1.06 A 100 μA
1.5 A 0 ≤ |I| ≤ 1.53 A
3 A 0 ≤ |I| ≤ 3.06 A 1 mA
10 A
a
a. Available for pulse mode. Not available for DC mode.
0 ≤ |I| ≤ 10.6 A
