Keysight B2961A/B2962A SCPI Command Reference, Edition 6 2- 45
Subsystem Command Summary
Controlling Source/Measure Trigger
:ARM[c]:ACQ[:LAY]:TOUT:SIGN output
{,output}
:ARM[c]:TRAN[:LAY]:TOUT:SIGN outpu
t{,output}
:ARM[c][:ALL][:LAY]:TOUT:SIGN outp
ut{,output}
:ARM[c]:ACQ[:LAY]:TOUT:SIGN?
:ARM[c]:TRAN[:LAY]:TOUT:SIGN?
Selects the trigger output for the status
change between the idle state and the arm
layer.
output=INT1|INT2|LAN|EXT1|EXT2|
EXT3|EXT4|EXT5|EXT6|EXT7|EXT8|
EXT9|EXT10|EXT11|EXT12|EXT13|
EXT14
EXT1
:ARM[c]:ACQ[:LAY]:TOUT[:STAT] mode
:ARM[c]:TRAN[:LAY]:TOUT[:STAT] mod
e
:ARM[c][:ALL][:LAY]:TOUT[:STAT] mo
de
:ARM[c]:ACQ[:LAY]:TOUT[:STAT]?
:ARM[c]:TRAN[:LAY]:TOUT[:STAT]?
Enables or disables the trigger output for
the status change between the idle state
and the arm layer.
mode=1|ON|0|OFF
OFF
:IDLE[c]:ACQ?
:IDLE[c]:TRAN?
:IDLE[c][:ALL]?
Checks the status of the specified device
action for the specified channel, and
waits until the status is changed to idle.
:INIT[:IMM]:ACQ [chanlist]
:INIT[:IMM]:TRAN [chanlist]
:INIT[:IMM][:ALL] [chanlist]
Initiates the specified device action for
the specified channel. Trigger status is
changed from idle to initiated.
chanlist=(@1)|(@2)|(@1,2)|(@1:2)|
(@2,1)|(@2:1)
:TRIG[c]:ACQ:BYP bypass
:TRIG[c]:TRAN:BYP bypass
:TRIG[c][:ALL]:BYP bypass
:TRIG[c]:ACQ:BYP?
:TRIG[c]:TRAN:BYP?
Enables or disables a bypass for the event
detector in the trigger layer.
bypass=ONCE|OFF
ONCE enables the bypass only for the
first passage.
OFF
Command Summary Reset setting
