Keysight B2961A/B2962A SCPI Command Reference, Edition 6 2- 47
Subsystem Command Summary
Controlling Source/Measure Trigger
:TRIG[c]:ACQ:SOUR[:SIGN] source
:TRIG[c]:TRAN:SOUR[:SIGN] source
:TRIG[c][:ALL]:SOUR[:SIGN] source
:TRIG[c]:ACQ:SOUR[:SIGN]?
:TRIG[c]:TRAN:SOUR[:SIGN]?
Selects the trigger source for the
specified device action.
source=AINT|BUS|TIMer|INT1|INT2|
LAN|EXT1|EXT2|EXT3|EXT4|EXT5|
EXT6|EXT7|EXT8|EXT9|EXT10|
EXT11|EXT12|EXT13|EXT14
AINT
:TRIG[c]:ACQ:TIM interval
:TRIG[c]:TRAN:TIM interval
:TRIG[c][:ALL]:TIM interval
:TRIG[c]:ACQ:TIM? [interval]
:TRIG[c]:TRAN:TIM? [interval]
:TRIG[c][:ALL]:TIM? interval
Sets the interval of the TIMer trigger
source for the specified device action.
interval=MINimum|MAXimum|
DEFault|1E-5 to 1E+5 seconds
Query does not support interval=1E-5 to
1E+5.
1E-5 seconds
:TRIG[c]:ACQ:TOUT:SIGN output{,out
put}
:TRIG[c]:TRAN:TOUT:SIGN output{,ou
tput}
:TRIG[c][:ALL]:TOUT:SIGN output{,o
utput}
:TRIG[c]:ACQ:TOUT:SIGN?
:TRIG[c]:TRAN:TOUT:SIGN?
Selects the trigger output for the status
change between the arm layer and the
trigger layer.
output=INT1|INT2|LAN|EXT1|EXT2|
EXT3|EXT4|EXT5|EXT6|EXT7|EXT8|
EXT9|EXT10|EXT11|EXT12|EXT13|
EXT14
EXT1
:TRIG[c]:ACQ:TOUT[:STAT] mode
:TRIG[c]:TRAN:TOUT[:STAT] mode
:TRIG[c][:ALL]:TOUT[:STAT] mode
:TRIG[c]:ACQ:TOUT[:STAT]?
:TRIG[c]:TRAN:TOUT[:STAT]?
Enables or disables the trigger output for
the status change between the arm layer
and the trigger layer.
mode=1|ON|0|OFF
OFF
Command Summary Reset setting
