Cable designation
Connector designation
Robot controller - robot
Connection
Motor cable X20 - X30 Harting HAN 16
HP
Data cable X21 - X31 Harting HAN 3A
+ HAN Q12
Ground conductor/equipo-
tential bonding (optional)
M8 ring cable
lug at both ends
Standard connecting cable
Fig. 7-10: Connecting cables, overview
KR IONTEC
184/344 | www.kuka.com MA KR IONTEC V4 | Issued: 11.05.2021
Start-up and recommissioning

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kuka IONTEC KR 20 R3100 and is the answer not in the manual?

Kuka IONTEC KR 20 R3100 Specifications

General IconGeneral
Payload20 kg
Reach3100 mm
Repeatability±0.06 mm
Number of Axes6
ControllerKR C4
Protection RatingIP65
Mounting PositionFloor, ceiling, wall
