Kyocera ECOSYS FS-C8650DN Service Manual

2MN/2N1
1-3-75
U140 Setting: [Mag AC]
1. Select the item to be set.
2. Change the setting value using the numeric keys.
*: 55 ppm model only.
3. Press the OK key. The value is set.
Setting: [Sleeve Freq]
1. Select the item to be set.
2. Change the setting value using the numeric keys.
*: 55 ppm model only.
3. Press the OK key. The value is set.
Setting: [Sleeve Duty]
1. Select the item to be set.
2. Change the setting value using the numeric keys.
*: 55 ppm model only.
3. Press the OK key. The value is set.
Item No. Description
Display Description
Setting
range
Initial setting
45ppm 55ppm
C Developer magnet roller AC bias
for cyan
0 to 255 200 200
M Developer magnet roller AC bias
for magenta
0 to 255 200 200
Y Developer magnet roller AC bias
for yellow
0 to 255 200 200
K Developer magnet roller AC bias
for black
0 to 255 160 160
B/W* Developer magnet roller AC bias
in black/white mode
0 to 255 - 160
Display Description
Setting
range
Initial setting
45ppm 55ppm
Normal Developer sleeve roller fre-
quency
0 to 6200 5345 5511
B/W* Developer sleeve roller fre-
quency in black/white mode
0 to 6200 - 5345
Half Developer sleeve roller fre-
quency (half speed)
0 to 6200 5345 5345
3/4* Developer sleeve roller fre-
quency at 3/4 times of line speed
0 to 6200 5345 5345
Display Description
Setting
range
Initial setting
45ppm 55ppm
Normal Developer sleeve roller duty 0 to 99 68 68
B/W* Developer sleeve roller duty in
black/white mode
0 to 99 - 68
