Kyocera ECOSYS FS-C8650DN Service Manual

2MN/2N1
2-3-20
YC11
15 GND - - Ground
Connected to
LSU relay
PWB
16 DATA_3PBK(LVD
S)
O 0/3.3 V DC (pulse) Video data signal K (P)
17 DATA_3NBK(LVD
S)
O 0/3.3 V DC (pulse) Video data signal K (N)
18 GND - - Ground
19 DATA_2P_M(LVD
S)
O 0/3.3 V DC (pulse) Video data signal M (P)
20 DATA_2N_M(LVD
S)
O 0/3.3 V DC (pulse) Video data signal M (N)
21 GND - - Ground
22 GAIN_FIX_M O 0/3.3 V DC APCPWB-M control signal
23 PALA_STG_P2_M O 0/3.3 V DC APCPWB-M control signal
24 PALA_STG_P1_M O 0/3.3 V DC APCPWB-M control signal
25 PALA_STG_P0_M O 0/3.3 V DC APCPWB-M control signal
26 INT_ST_M O 0/3.3 V DC APCPWB-M control signal
27 GND - - Ground
28 DATA_2P_C(LVD
S)
O 0/3.3 V DC (pulse) Video data signal C (P)
29 DATA_2N_C(LVD
S)
O 0/3.3 V DC (pulse) Video data signal C (N)
30 GND - - Ground
31 GAIN_FIX_C O 0/3.3 V DC APCPWB-C control signal
32 PALA_STG_P2_C O 0/3.3 V DC APCPWB-C control signal
33 PALA_STG_P1_C O 0/3.3 V DC APCPWB-C control signal
34 PALA_STG_P0_C O 0/3.3 V DC APCPWB-C control signal
35 INT_ST_C O 0/3.3 V DC APCPWB-C control signal
36 GND - - Ground
37 DATA_2P_Y(LVD
S)
O 0/3.3 V DC (pulse) Video data signal Y (P)
38 DATA_2N_Y(LVD
S)
O 0/3.3 V DC (pulse) Video data signal Y (N)
39 GND - - Ground
40 GAIN_FIX_Y O 0/3.3 V DC APCPWB-Y control signal
41 PALA_STG_P2_Y O 0/3.3 V DC APCPWB-Y control signal
42 PALA_STG_P1_Y O 0/3.3 V DC APCPWB-Y control signal
43 PALA_STG_P0_Y O 0/3.3 V DC APCPWB-Y control signal
44 INT_ST_Y O 0/3.3 V DC APCPWB-Y control signal
45 GND - - Ground
Connector Pin Signal I/O Voltage Description
