Kyocera ECOSYS FS-C8650DN Service Manual

2MN/2N1
2-3-21
YC11
46 EEPROM_CS_1_
BK
I/O 0/3.3 V DC (pulse) APCPWB-K EEPROM data signal
Connected to
LSU relay
PWB
47 IDD_CS_1_BK O 0/3.3 V DC APCPWB-K control signal
48 EEPROM_CS_2_
BK
I/O 0/3.3 V DC (pulse) APCPWB-K EEPROM data signal
49 IDD_CS_2_BK O 0/3.3 V DC APCPWB-K control signal
50 EEPROM_CS_M I/O 0/3.3 V DC (pulse) APCPWB-M EEPROM data signal
51 IDD_CS_M O 0/3.3 V DC APCPWB-M control signal
52 EEPROM_CS_C I/O 0/3.3 V DC (pulse) APCPWB-C EEPROM data signal
53 IDD_CS_C O 0/3.3 V DC APCPWB-C control signal
54 EEPROM_CS_Y I/O 0/3.3 V DC (pulse) APCPWB-Y EEPROM data signal
55 IDD_CS_Y O 0/3.3 V DC APCPWB-Y control signal
56 SGND - - Ground
57 MSET_N O 0/3.3 V DC Control signal
58 SGND - - Ground
59 SDO O 0/3.3 V DC (pulse) Serial communication data signal
60 SGND - - Ground
61 SDI I 0/3.3 V DC (pulse) Serial communication data signal
62 SGND - - Ground
63 CLK O 0/3.3 V DC (pulse) Clock signal
64 SGND - - Ground
YC12
1-
Connected to
LSU relay
PWB
2 LOCK_BK I 0/3.3 V DC PM-K lock signal
3 REM_BK O 0/24 V DC PM-K: On/Off
4 GND - - Ground
5 DATA_1PBK O 0/3.3 V DC (pulse) Video data signal K (P)
6 DATA_1NBK O 0/3.3 V DC (pulse) Video data signal K (N)
7 GND - - Ground
8 SDCLK_BK O 0/3.3 V DC (pulse) APCPWB-K clock signal
9 GND - - Ground
10 PARA_SIG_P4_B
K
O 0/3.3 V DC APCPWB-K control signal
11 PARA_SIG_P3_B
K
O 0/3.3 V DC APCPWB-K control signal
12 CUALM_BK I 0/3.3 V DC APCPWB-K alarm signal
Connector Pin Signal I/O Voltage Description
