2MN/2N1
2-3-22
YC12
13 LSU_TH_BK I Analog LSU thermistor K detection signal
Connected to
LSU relay
PWB
14 BD_BK I 0/3.3 V DC (pulse) Horizontal synchronization signal K
15 GND - - Ground
16 CLK_M O 0/3.3 V DC (pulse) PM-M clock signal
17 LOCK_M I 0/3.3 V DC PM-M lock signal
18 REM_M O 0/24 V DC PM-M: On/Off
19 GND - - Ground
20 DATA_1P_M O 0/3.3 V DC (pulse) Video data signal M (P)
21 DATA_1N_M O 0/3.3 V DC (pulse) Video data signal M (N)
22 GND - - Ground
23 SDCLK_M O 0/3.3 V DC (pulse) APCPWB-M clock signal
24 SGND - - Ground
25 PARA_SIG_P4_M O 0/3.3 V DC APCPWB-M control signal
26 PARA_SIG_P3_M O 0/3.3 V DC APCPWB-M control signal
27 CUALM_M I 0/3.3 V DC APCPWB-M alarm signal
28 LSU_TH_M I Analog LSU thermistor M detection signal
29 BD_M I 0/3.3 V DC (pulse) Horizontal synchronization signal M
30 GND - - Ground
31 CLK_C O 0/3.3 V DC (pulse) PM-C clock signal
32 LOCK_C I 0/3.3 V DC PM-C lock signal
33 REM_C O 0/24 V DC PM-C: On/Off
34 GND - - Ground
35 DATA_1P_C O 0/3.3 V DC (pulse) Video data signal C (P)
36 DATA_1N_C O 0/3.3 V DC (pulse) Video data signal C (N)
37 GND - - Ground
38 SDCLK_C O 0/3.3 V DC (pulse) APCPWB-C clock signal
39 GND - - Ground
40 PARA_SIG_P4_C O 0/3.3 V DC APCPWB-C control signal
41 PARA_SIG_P3_C O 0/3.3 V DC APCPWB-C control signal
42 CUALM_C I 0/3.3 V DC APCPWB-C alarm signal
43 LSU_TH_C I Analog LSU thermistor C detection signal
44 BD_C I 0/3.3 V DC (pulse) Horizontal synchronization signal C
45 GND - - Ground
46 CLK_Y O 0/3.3 V DC (pulse) PM-Y clock signal
47 LOCK_Y I 0/3.3 V DC PM-Y lock signal
48 REM_Y O 0/24 V DC PM-Y: On/Off
49 GND - - Ground
Connector Pin Signal I/O Voltage Description
To Next Page
