2MN/2N1
2-3-23
YC12
50 DATA_1P_Y O 0/3.3 V DC (pulse) Video data signal Y (P)
Connected to
LSU relay
PWB
51 DATA_1N_Y O 0/3.3 V DC (pulse) Video data signal Y (N)
52 GND - - Ground
53 SDCLK_Y O 0/3.3 V DC (pulse) APCPWB-Y clock signal
54 GND - - Ground
55 PARA_SIG_P4_Y O 0/3.3 V DC APCPWB-Y control signal
56 PARA_SIG_P3_Y O 0/3.3 V DC APCPWB-Y control signal
57 CUALM_Y I 0/3.3 V DC APCPWB-Y alarm signal
58 LSU_TH_Y I Analog LSU thermistor Y detection signal
59 BD_Y I 0/3.3 V DC (pulse) Horizontal synchronization signal Y
60 GND - - Ground
YC13
1 GND - - Ground
Connected to
feed PWB 1
2 GND - - Ground
3 3.3V3 I 3.3 V DC 3.3 V DC power from FPWB1
4 3.3V2 I 3.3 V DC 3.3 V DC power from FPWB1
YC15 1GND - -
Ground
Connected to
the LSU relay
PWB
2 +3.3V2 O
3.3 V DC
3.3 V DC power to LSURPWB
3GND - -
Ground
4GND - -
Ground
5+5V_AN O
5 V DC
5 V DC power to LSURPWB
6+5V_AN O
5 V DC
5 V DC power to LSURPWB
Connector Pin Signal I/O Voltage Description
To Next Page
