2MN/2N1
2-3-24
YC16
1 GND - - Ground
Connected to
high voltage
PWB 1
2 AC_MAIN_CLK O 0/3.3 V DC (pulse) AC charger roller Y clock signal
3 DC_MAIN_REM O 0/3.3 V DC DC main charger Y: On/Off
4 DC_MAIN_CNT_
Y
O PWM DC charger roller Y control signal
5 MAIN_IDC_Y O PWM DC charger roller Y control signal
6 AC_SLV_CLK_Y O 0/3.3 V DC (pulse) AC sleeve bias Y clock signal
7 DC_SLV_CNT_Y O PWM DC sleeve bias Y control voltage
8 DC_MAG_CNT_Y O PWM DC magnet bias Y control voltage
9 AC_SLV_CNT_Y O PWM AC sleeve bias Y control voltage
10 AC_MAIN_CNT_
Y
O PWM AC charger roller Y control signal
11 DISCHARGE_Y I PWM Main charger Y control signal
12 AC_MAG_CNT_Y O 0/3.3 V DC (pulse) AC magnet bias Y control voltage
13 AC_MAG_CLK_Y O 0/3.3 V DC (pulse) AC magnet bias Y clock signal
14 DC_REC_CNT O PWM DC bias Y control voltage
15 N.C - - Not used
16 DC_REC_REM O PWM DC bias C control voltage
17 AC_MAG_CLK_C O 0/3.3 V DC (pulse) AC magnet bias C clock signal
18 AC_MAG_CNT_C O 0/3.3 V DC (pulse) AC magnet bias C control voltage
19 DISCHARGE_C I PWM Main charger C control signal
20 AC_MAIN_CNT_
C
O PWM AC charger roller C control signal
21 AC_SLV_CNT_C O PWM AC sleeve bias C control voltage
22 DC_MAG_CNT_C O PWM DC magnet bias C control voltage
23 DC_SLV_CNT_C O PWM DC sleeve bias C control voltage
24 AC_SLV_CLK_C O 0/3.3 V DC (pulse) AC sleeve bias C clock signal
25 DC_MAG_REM O 0/3.3 V DC DC main charger C: On/Off
26 MAIN_IDC_C O PWM DC charger roller C control signal
27 DC_MAIN_CNT_
C
O PWM DC charger roller C control signal
28 GND - - Ground
Connector Pin Signal I/O Voltage Description
