2MN/2N1
2-3-25
YC17
1 GND - - Ground
Connected to
high voltage
PWB 1
2 DC_MAIN_CNT_
M
O PWM DC charger roller Y control signal
3 MAIN_IDC_M O PWM DC charger roller M control signal
4 AC_SLV_CLK_M O 0/3.3 V DC (pulse) AC sleeve bias M clock signal
5 DC_SLV_CNT_M O PWM DC sleeve bias M control voltage
6 DC_MAG_CNT_
M
O PWM DC magnet bias M control voltage
7 AC_SLV_CNT_M O PWM AC sleeve bias M control voltage
8 AC_MAIN_CNT_
M
O PWM AC charger roller M control signal
9 DISCHARGE_M I PWM Main charger M control signal
10 AC_MAG_CNT_M O 0/3.3 V DC (pulse) AC magnet bias M control voltage
11 AC_MAG_CLK_M O 0/3.3 V DC (pulse) AC magnet bias M clock signal
12 AC_MAG_CLK_B
k
O PWM DC charger roller K control signal
13 AC_MAG_CNT_B
k
O PWM DC charger roller K control signal
14 DISCHARGE_Bk I PWM Main charger K control signal
15 AC_SLV_CNT_Bk O 0/3.3 V DC (pulse) AC sleeve bias K clock signal
16 DC_MAG_CNT_B
k
O PWM DC sleeve bias K control voltage
17 DC_SLV_CNT_Bk O PWM DC magnet bias K control voltage
18 AC_SLV_CLK_Bk O PWM AC sleeve bias K control voltage
19 AC_MAIN_CNT_
Bk
O PWM AC charger roller K control signal
20 MAIN_IDC_Bk O PWM DC charger roller K control signal
21 DC_MAIN_CNT_
Bk
O PWM DC charger roller K control signal
22 GND - - Ground
YC18
1 DF_CLK O 0/3.3 V DC (pulse) DFMPWB clock signal
Connected to
1000-sheet/
4000-sheet
finisher
2 DF_SDO O 0/3.3 V DC (pulse) DFMPWB serial communication data
signal
3 DF_SEL O 0/3.3 V DC DFMPWB select signal
4 DF_SDI O 0/3.3 V DC (pulse) DFMPWB serial communication data
signal
5 DF_RDY I 0/3.3 V DC DFMPWB ready signal
6 DF_DET O 0/3.3 V DC DFMPWB detection signal
7 GND - - Ground
Connector Pin Signal I/O Voltage Description
