2MN/2N1
2-3-42
YC9
1 TPD_TEMP_BK I Analog Developer thermistor K detection sig-
nal
Connected to
developer
unit K
2 DLP_VCONT_BK
_1
O 0/3.3 V DC DEVPWB-K control signal
3 TPD_BK_1 I Analog DEVPWB-K detection signal
4 TN_CLK_BK O 0/3.3 V DC (pulse) Clock signal
5 GND - - Ground
6 DLP_ADR1_BK - - Not used
7 DLP_ADR0_BK - - Not used
8 EEP_SDA1 I/O 0/3.3 V DC (pulse) EEPROM data signal
9 EEP_SCL1 O 0/3.3 V DC (pulse) EEPROM clock signal
10 3.3V2 O 3.3 V DC 3.3 V DC power to TS-K
11 3V O 3.3 V DC 3.3 V DC power to VM-K
12 VIB_MOT O 0/24 V DC VM-K: On/Off
YC10
1 3.3V2 O 3.3 V DC 3.3 V DC power to DRPWB-M
Connected to
drum unit M
2 EEP_SCL1 O 0/3.3 V DC (pulse) EEPROM clock signal
3 EEP_SDA1 I/O 0/3.3 V DC (pulse) EEPROM data signal
4 GND - - Ground
5 DRM_ADR0_M - - Not used
6 DRM_ADR1_M - - Not used
7 24V O 24 V DC 24 V DC power to CL-M
8 ERS_M_REM O 0/24 V DC CL-M: On/Off
YC11
1 TPD_TEMP_M I Analog Developer thermistor M detection sig-
nal
Connected to
developer
unit M
2 DLP_VCONT_M_
1
O 0/3.3 V DC DEVPWB-M control signal
3 TPD_M_1 I Analog DEVPWB-M detection signal
4 TN_CLK_M O 0/3.3 V DC (pulse) Clock signal
5 GND - - Ground
6 DLP_ADR1_M - - Not used
7 DLP_ADR0_M - - Not used
8 EEP_SDA1 I/O 0/3.3 V DC (pulse) EEPROM data signal
9 EEP_SCL1 O 0/3.3 V DC (pulse) EEPROM clock signal
10 3.3V2 O 3.3 V DC 3.3 V DC power to TS-M
11 3V O 3.3 V DC 3.3 V DC power to VM-M
12 VIB_MOT O 0/24 V DC VM-M: On/Off
