2MN/2N1
2-3-43
YC12
1 3.3V2 O 3.3 V DC 3.3 V DC power to DRPWB-C
Connected to
drum unit C
2 EEP_SCL1 O 0/3.3 V DC (pulse) EEPROM clock signal
3 EEP_SDA1 I/O 0/3.3 V DC (pulse) EEPROM data signal
4 GND - - Ground
5 DRM_ADR0_C - - Not used
6 DRM_ADR1_C - - Not used
7 24V O 24 V DC 24 V DC power to CL-C
8 ERS_C_REM O 0/24 V DC CL-C: On/Off
YC13
1 TPD_TEMP_C I Analog Developer thermistor C detection sig-
nal
Connected to
developer
unit C
2 DLP_VCONT_C_
1
O 0/3.3 V DC DEVPWB-C control signal
3 TPD_C_1 I Analog DEVPWB-C detection signal
4 TN_CLK_C O 0/3.3 V DC (pulse) Clock signal
5 GND - - Ground
6 DLP_ADR1_C - - Not used
7 DLP_ADR0_C - - Not used
8 EEP_SDA1 I/O 0/3.3 V DC (pulse) EEPROM data signal
9 EEP_SCL1 O 0/3.3 V DC (pulse) EEPROM clock signal
10 3.3V2 O 3.3 V DC 3.3 V DC power to TS-C
11 3V O 3.3 V DC 3.3 V DC power to VM-C
12 VIB_MOT O 0/24 V DC VM-C: On/Off
YC14
1 3.3V2 O 3.3 V DC 3.3 V DC power to DRPWB-Y
Connected to
drum unit Y
2 EEP_SCL1 O 0/3.3 V DC (pulse) EEPROM clock signal
3 EEP_SDA1 I/O 0/3.3 V DC (pulse) EEPROM data signal
4 GND - - Ground
5 DRM_ADR0_ Y - - Not used
6 DRM _ADR1_ Y - - Not used
7 24V O 24 V DC 24 V DC power to CL-Y
8 ERS_ Y _REM O 0/24 V DC CL-Y: On/Off
Connector Pin Signal I/O Voltage Description
To Next Page
