Kyocera ECOSYS FS-C8650DN Service Manual

2MN/2N1
2-3-48
YC1
33 MPF_DOWN O 0/3.3 V DC MPLS2: On/Off
Connected to
engine PWB
34 MPF_UP O 0/3.3 V DC MPLS1: On/Off
35 MPF_PPR O 0/3.3 V DC MPPS: On/Off
36 GND - - Ground
37 MPF_LNG O 0/3.3 V DC MPPLSW: On/Off
38 MPF_WID3 O 0/3.3 V DC MPPWSW: On/Off
39 MPF_WID2 O 0/3.3 V DC MPPWSW: On/Off
40 MPF_WID1 O 0/3.3 V DC MPPWSW: On/Off
41 MPF_TABLE O 0/3.3 V DC MPTSW: On/Off
42 GND - - Ground
43 FSR_MOT_BRK I 0/3.3 V DC FUM break signal
44 FSR_MOT_DIR I 0/3.3 V DC FUM drive switch signal
45 FSR_MOT_RDY O 0/3.3 V DC FUM ready signal
46 FSR_MOT_CLK I 0/3.3 V DC (pulse) FUM clock signal
47 FSR_MOT_REM I 0/3.3 V DC FUM: On/Off
48 GND - - Ground
49 GND - - Ground
50 EXIT_REAR_FAN
_H
I 0/24 V DC ERFM: On/Off
51 EXIT_REAR_FAN
_L
I 0/24 V DC ERFM: On/Off
52 PRESS_REM - - Not used
53 FSR_RELAY I 0/3.3 V DC Fuser relay signal
54 ZEROC - - Not used
55 SUB_HEAT_REM - - Not used
56 MAIN_HEAT_RE
M
- - Not used
57 GND - - Ground
58 JOB_SOL_REM I 0/24 V DC JSFSSOL: On/Off
59 JOB_OPEN_SEN
S
O 0/3.3 V DC JSOCS: On/Off
60 JOB_MOT_DIR I 0/3.3 V DC JSEM drive switch signal
61 JOB_MOT_CLK I 0/3.3 V DC (pulse) JSEM clock signal
62 JOB_MOT_REM I 0/3.3 V DC JSEM: On/Off
63 JOB_SET O 0/3.3 V DC Job separator set signal
64 GND - - Ground
Connector Pin Signal I/O Voltage Description
