Kyocera ECOSYS FS-C8650DN Service Manual

2MN/2N1
2-3-49
YC2
1 GND - - Ground
Connected to
engine PWB
2 GND - - Ground
3 DRM_HEAT_REM - - Not used
4 POWER_OFF I 0/3.3 V DC Power off signal
5 IH_PWB_FAN_AL
M
O 0/3.3 V DC IHFM alarm signal
6 IH_PWB_FAN_H I 0/24 V DC IHFM: On/Off
7 IH_PWB_FAN_L - - Not used
8 GND - - Ground
9 REG_MOT_REM(
CL)
I 0/3.3 V DC RM/RCL: On/Off
10 REG_MOT_CLK I 0/3.3 V DC (pulse) RM clock signal
11 REG_MOT_PD I 0/3.3 V DC RM control signal
12 GND - - Ground
13 DLP_MOT_CLR_
DIR
- - Not used
14 DLP_MOT_CLR_
RDY
- - Not used
15 DLP_MOT_CLR_
CLK
- - Not used
16 DLP_MOT_CLR_
REM
- - Not used
17 GND - - Ground
18 DRM_MOT_CLR_
DIR
- - Not used
19 DRM_MOT_CLR_
RDY
- - Not used
20 DRM_MOT_BK_C
LR_CLK
- - Not used
21 DRM_MOT_CLR_
REM
- - Not used
22 GND - - Ground
23 DLP_MOT_BK_DI
R
- - Not used
24 DLP_MOT_BK_R
DY
- - Not used
25 DLP_MOT_BK_C
LK
- - Not used
26 DLP_MOT_BK_R
EM
- - Not used
Connector Pin Signal I/O Voltage Description
