Kyocera ECOSYS FS-C8650DN Service Manual

2MN/2N1
2-3-59
YC3
12 GND - - Ground
Connected to
paper length
switch 1/2,
paper width
switch 1/2, lift
motor 1/2,
paper gauge
sensor 1(U)/
(L) and paper
gauge sen-
sor 2(U)/(L)
13 LIFT_MOT1_RET O 0/24 V DC LM1: On/Off
14 LIFT_MOT1_DR O 0/24 V DC LM1: On/Off
15 LIFT_MOT2_RET O 0/24 V DC LM2: On/Off
16 LIFT_MOT2_DR O 0/24 V DC LM2: On/Off
17 LED_5V O 5 V DC 5 V DC power to PGS1(U)
18 GND - - Ground
19 CAS1_QUANT1 I 0/3.3 V DC PGS1(U): On/Off
20 LED_5V O 5 V DC 5 V DC power to PGS1(L)
21 GND - - Ground
22 CAS1_QUANT2 I 0/3.3 V DC PGS1(L): On/Off
23 LED_5V O 5 V DC 5 V DC power to PGS2(U)
24 GND - - Ground
25 CAS2_QUANT1 I 0/3.3 V DC PGS2(U): On/Off
26 LED_5V O 5 V DC 5 V DC power to PGS2(L)
27 GND - - Ground
28 CAS2_QUANT2 I 0/3.3 V DC PGS2(L): On/Off
YC4
1 FEED_CL1_REM O 0/24 V DC PFCL1: On/Off
Connected to
paper feed
clutch 1/2
2 24V2 O 24 V DC PFCL124 V DC power to PFCL1
3 FEED_CL2_REM O 0/24 V DC PFCL2: On/Off
4 24V2 O 24 V DC 24 V DC power to PFCL2
YC5
1 NC - - Not used
Connected to
paper con-
veying clutch
2 24V2 O 24 V DC 24 V DC power to PCCL
3 V-FEED_CL O 0/24 V DC PCCL: On/Off
YC6
1 LED_5V O 5 V DC 5 V DC power to PCS
Connected to
paper con-
veying sen-
sor and
paper con-
veying cover
switch
2 GND - - Ground
3 FEED2_SENS I 0/3.3 V DC PCS: On/Off
4 FEED_COVER_O
PEN
I 0/3.3 V DC PCCSW: On/Off
5 GND - - Ground
Connector Pin Signal I/O Voltage Description
