2MN/2N1
2-3-60
YC7
1 MID_B/ O 0/24 V DC (pulse) MM drive control signal
Connected to
middle motor,
regist deflec-
tion sensor,
middle sen-
sor and reg-
istration
sensor
2 MID_A/ O 0/24 V DC (pulse) MM drive control signal
3 MID_B O 0/24 V DC (pulse) MM drive control signal
4 MID_A O 0/24 V DC (pulse) MM drive control signal
5 BEND_SENS I 0/3.3 V DC RDS: On/Off
6 GND - - Ground
7 5V O 5 V DC 5 V DC power to RDS
8 GND - - Ground
9 FEED1_SENS I 0/3.3 V DC MS: On/Off
10 5V O 5 V DC 5 V DC power to MS
11 GND - - Ground
12 REG_SENS I 0/3.3 V DC RS: On/Off
13 5V O 5 V DC 5 V DC power to RS
14 MID_CL_REM O 0/24 V DC MCL: On/Off
15 24V2 O 24 V DC 24 V DC power to MCL
YC8
1 24V2 O 24 V DC 24 V DC power to PUSOL1
Connected to
primary
paper feed
unit
2 PICK_SOL1_REM O 0/24 V DC PUSOL1: On/Off (ACT)
3 PICK_SOL1_RET O 0/24 V DC PUSOL1: On/Off (RET)
4 LED_5V O 5 V DC 5 V DC power to PS1
5 GND - - Ground
6 CAS1_EMPTY_S
ENS
I 0/3.3 V DC PS1: On/Off
7 LED_5V O 5 V DC 5 V DC power to LS1
8 GND - - Ground
9 CAS1_LIFT_UP_
SENS
I 0/3.3 V DC LS1: On/Off
10 5V O 5 V DC 5 V DC power to FS1
11 CAS1_P0_SENS I 0/3.3 V DC FS1: On/Off
12 GND - - Ground
13 24V2 O 24 V DC 24 V DC power to PUSOL2
14 PICK_SOL2_REM O 0/24 V DC PUSOL2: On/Off (ACT)
15 PICK_SOL2_RET O 0/24 V DC PUSOL2: On/Off (RET)
16 LED_5V O 5 V DC 5 V DC power to PS2
17 GND - - Ground
18 CAS2_EMPTY_S
ENS
I 0/3.3 V DC PS2: On/Off
19 LED_5V O 5 V DC 5 V DC power to LS2
Connector Pin Signal I/O Voltage Description
