Kyocera ECOSYS FS-C8650DN Service Manual

2MN/2N1
2-3-63
Connector Pin Signal I/O Voltage Description
YC1
1 GND - - Not used
Connected to
feed PWB 1
2 DU2_A I 0/24 V DC (pulse) DUM2 drive control signal
3 DU2_B I 0/24 V DC (pulse) DUM2 drive control signal
4 DU2_A/ I 0/24 V DC (pulse) DUM2 drive control signal
5 DU2_B/ I 0/24 V DC (pulse) DUM2 drive control signal
6 DU_OPEN_SW O 0/3.3 V DC DUCSW: On/Off
7 DU_CL_LOWER_
REM
I 0/24 V DC DUCL2: On/Off
8 DU_FAN - - Not used
9 24V2 I 24 V DC 24 V DC power from FPWB1
10 PRESS_RLS_RE
M2
I 0/24 V DC TRRM: On/Off
11 PRESS_RLS_RE
M1
I 0/24 V DC TRRM: On/Off
12 5V I 5 V DC 5 V DC power from FPWB1
13 PRESS_RLS_SE
NS
O 0/3.3 V DC TRRS: On/Off
14 DU_SENS O 0/3.3 V DC DUS2: On/Off
15 BELT_JAM_SENS - - Not used
16 REG_BK_SENS1
_S
- - Not used
17 REG_BK_SENS1
_P
- - Not used
18 REG_BK_LED - - Not used
YC2
1 GND - - Ground
Connected to
MP tray unit
2 MPF_LNG I 0/3.3 V DC MPPLSW: On/Off
3 5V O 5 V DC 5 V DC power to MPPLSW
4 MPF_WID3 I 0/3.3 V DC MPPWSW: On/Off
5 MPF_WID2 I 0/3.3 V DC MPPWSW: On/Off
6 GND - - Ground
7 MPF_WID1 I 0/3.3 V DC MPPWSW: On/Off
8 GND - - Ground
9 MPF_TABLE I 0/3.3 V DC MPTSW: On/Off
