2MN/2N1
2-3-64
YC3
1 LED_3.3V3 O 3.3 V DC 3.3 V DC power to MPPLSW
Connected to
MP tray unit
2 GND - - Ground
3 MPF_PPR_SET I 0/3.3 V DC MPPS: On/Off
4 GND - - Ground
5 MPF_LIFT_UP_S
ENS
I 0/3.3 V DC MPLS1: On/Off
6 5V O 5 V DC 5 V DC power to MPLS1
7 GND - - Ground
8 MPF_LIFT_DOW
N_SENS
I 0/3.3 V DC MPLS2: On/Off
9 5V O 5 V DC 5 V DC power to MPLS1
10 GND - - Ground
11 MPF_JAM_SENS I 0/3.3 V DC MPFS: On/Off
12 5V O 5 V DC 5 V DC power to MPFS
13 MPF_CL_REM O 0/24 V DC MPPFCL: On/Off
14 24V2 O 24 V DC 24 V DC power to MPPFCL
15 MPF_LIFT_DR_A O 0/24 V DC MPLM: On/Off
16 MPF_LIFT_DR_B O 0/24 V DC MPLM: On/Off
YC7
1 24V2 - - Not used
Connected to
duplex clutch
2, duplex
cover switch
and duplex
motor 2
2 DU_CL2_REM - - Not used
3 DU_OPEN I 0/3.3 V DC DUCSW: On/Off
4 GND - - Ground
5 DU2_B/ O 0/24 V DC (pulse) DUM2 drive control signal
6 DU2_A/ O 0/24 V DC (pulse) DUM2 drive control signal
7 DU2_B O 0/24 V DC (pulse) DUM2 drive control signal
8 DU2_A O 0/24 V DC (pulse) DUM2 drive control signal
YC9
1 GND - - Ground
Connected to
duplex sen-
sor 2
2 DU_SENS I 0/3.3 V DC DUS2: On/Off
3 5V O 5 V DC 5 V DC power to DUS2
Connector Pin Signal I/O Voltage Description
