Kyocera ECOSYS FS-C8650DN Service Manual

2MN/2N1
2-3-79
YC8
21 PALA_SIG P3 M O 0/3.3 V DC APCPWB-M control signal
Connected to
APC PWB M
22 PALA_SIG P4 M O 0/3.3 V DC APCPWB-M control signal
23 SDCLK M O 0/3.3 V DC (pulse) APCPWB-M clock signal
24 GAIN FIX M O 0/3.3 V DC APCPWB-M control signal
25 DATA_1N_M(LVD
S)
O 0/3.3 V DC (pulse) Video data signal M (N)
26 DATA_1P_M(LVD
S)
O 0/3.3 V DC (pulse) Video data signal M (P)
27 SGND - - Ground
28 DATA_2N_M(LVD
S)
O 0/3.3 V DC (pulse) Video data signal M (N)
29 DATA_2P_M(LVD
S)
O 0/3.3 V DC (pulse) Video data signal M (P)
30 SGND - - Ground
YC9
1 24V O 24 V DC 24 V DC power to PM-C
Connected to
polygon
motor C
2PGND - - Ground
3 P_REM C O 0/24 V DC PM-C: On/Off
4 P_LOCK C I 0/3.3 V DC PM-C lock signal
5 P_CLK C O 0/3.3 V DC (pulse) PM-C clock signal
YC10
1SGND - - Ground
Connected to
APC PWB C
2 BD C I 0/3.3 V DC (pulse) Horizontal synchronization signal C
3 LSU_TH C I Analog LSU thermistor C detection signal
4 - - - Not used
5 - - - Not used
6 +5V O 5 V DC 5 V DC power to APCPWB-C
7 +5V O 5 V DC 5 V DC power to APCPWB-C
8 +5V O 5 V DC 5 V DC power to APCPWB-C
9 LDD_CS C O 0/3.3 V DC APCPWB-C control signal
10 SDI C I 0/3.3 V DC (pulse) Serial communication data signal
11 SDO C O 0/3.3 V DC (pulse) Serial communication data signal
12 CLK C O 0/3.3 V DC (pulse) APCPWB-C clock signal
13 EEPROM CS 0 C I/O 0/3.3 V DC (pulse) APCPWB-C EEPROM data signal
14 MSET_N O 0/3.3 V DC APCPWB-C control signal
15 CUALM C I 0/3.3 V DC APCPWB-C alarm signal
Connector Pin Signal I/O Voltage Description
