Kyocera ECOSYS FS-C8650DN Service Manual

2MN/2N1
2-3-80
YC10
16 - - - -
Connected to
APC PWB C
17 INT_ST C O 0/3.3 V DC APCPWB-C control signal
18 PALA_SIG P0 C O 0/3.3 V DC APCPWB-C control signal
19 PALA_SIG P1 C O 0/3.3 V DC APCPWB-C control signal
20 PALA_SIG P2 C O 0/3.3 V DC APCPWB-C control signal
21 PALA_SIG P3 C O 0/3.3 V DC APCPWB-C control signal
22 PALA_SIG P4 C O 0/3.3 V DC APCPWB-C control signal
23 SDCLK C O 0/3.3 V DC (pulse) APCPWB-C clock signal
24 GAIN FIX C O 0/3.3 V DC APCPWB-C control signal
25 DATA_1N_C(LVD
S)
O 0/3.3 V DC (pulse) Video data signal C (N)
26 DATA_1P_C(LVD
S)
O 0/3.3 V DC (pulse) Video data signal C (P)
27 SGND - - Ground
28 DATA_2N_C(LVD
S)
O 0/3.3 V DC (pulse) Video data signal C (N)
29 DATA_2P_C(LVD
S)
O 0/3.3 V DC (pulse) Video data signal C (P)
30 SGND - - Ground
YC11
1 24V O 24 V DC 24 V DC power to PM-Y
Connected to
polygon
motor Y
2PGND - - Ground
3 P_REM Y O 0/24 V DC PM-Y: On/Off
4 P_LOCK Y I 0/3.3 V DC PM-Y lock signal
5 P_CLK Y O 0/3.3 V DC (pulse) PM-Y clock signal
YC12
1SGND - - Ground
Connected to
APC PWB Y
2 BD Y I 0/3.3 V DC (pulse) Horizontal synchronization signal Y
3 LSU_TH Y I Analog LSU thermistor Y detection signal
4 - - - Not used
5 - - - Not used
6 +5V O 5 V DC 5 V DC power to APCPWB-Y
7 +5V O 5 V DC 5 V DC power to APCPWB-Y
8 +5V O 5 V DC 5 V DC power to APCPWB-Y
9 LDD_CS Y O 0/3.3 V DC APCPWB-Y control signal
10 SDI Y I 0/3.3 V DC (pulse) Serial communication data signal
Connector Pin Signal I/O Voltage Description
