2MN/2N1
2-3-81
YC12
11 SDO Y O 0/3.3 V DC (pulse) Serial communication data signal
Connected to
APC PWB Y
12 CLK Y O 0/3.3 V DC (pulse) APCPWB-Y clock signal
13 EEPROM CS Y I/O 0/3.3 V DC (pulse) APCPWB-Y EEPROM data signal
14 MSET_N O 0/3.3 V DC APCPWB-Y control signal
15 CUALM Y I 0/3.3 V DC APCPWB-Y alarm signal
16 - - - -
17 INT_ST Y O 0/3.3 V DC APCPWB-Y control signal
18 PALA_SIG P0 Y O 0/3.3 V DC APCPWB-Y control signal
19 PALA_SIG P1 Y O 0/3.3 V DC APCPWB-Y control signal
20 PALA_SIG P2 Y O 0/3.3 V DC APCPWB-Y control signal
21 PALA_SIG P3 Y O 0/3.3 V DC APCPWB-Y control signal
22 PALA_SIG P4 Y O 0/3.3 V DC APCPWB-Y control signal
23 SDCLK Y O 0/3.3 V DC (pulse) APCPWB-Y clock signal
24 GAIN FIX Y O 0/3.3 V DC APCPWB-Y control signal
25 DATA_1N_Y(LVD
S)
O 0/3.3 V DC (pulse) Video data signal Y (N)
26 DATA_1P_Y(LVD
S)
O 0/3.3 V DC (pulse) Video data signal Y (P)
27 SGND - - Ground
28 DATA_2N_Y(LVD
S)
O 0/3.3 V DC (pulse) Video data signal Y (N)
29 DATA_2P_Y(LVD
S)
O 0/3.3 V DC (pulse) Video data signal Y (P)
30 SGND - - Ground
Connector Pin Signal I/O Voltage Description
