Leica Captivate - Antenna Reference Planes, ARP

For Leica antennas: For non-Leica antennas:
Are handled automatically in the
standar
d antenna records.
Can be stored in a newly created
antenna record.
OR
Antenna records including azimuth
and elevation-dependent corrections
must be created using Infinity or
imported using the ANTEX format.
The antenna calibrations to determine the phase centre offsets of all Leica
ant
ennas were executed by Geo++® GmbH.
24.2 Antenna Reference Planes, ARP
The Antenna Reference Plane
•
is where the an
tenna heights are measured to.
•
is where the phase centre offsets refer to.
•
varies for different antennas.
GS_031
a
a The mechanical reference
plane is the underside o
f the
threaded metal insert.
a
GS_127
a The Antenna Reference Plane
is the under
side o
f the
thread.
0014496_001
a
a Antenna reference plane
(ARP)
Vertical phase centre
offse
ts
General
GS15
GS16/GS14/GS08plus
GS18
Antenna Heights 293
