Key Description
Result 1 or
R
esult 2
To view the first and second result.
Stake To access the Stakeout app and stake out the calculated
COGO point.
Page To change to another page on this panel.
Fn Tools Refer to "37 Apps - The Toolbox".
Next step
On the Code
page, type in a code if desired.
On the 3D viewer page, the points defining the area and the points of the
new border are shown in black.
Store stores the results.
38.10 COGO Calculation - Angle Method
Select Angle fr
om the COGO menu.
For all point fields, the 3D viewer can be used to select the desired point.
To typ
e in coordinates for a known point open a selectable list. Press New to
create a point.
Key Description
Calculate To calculate the result.
Meas app To measure a point manually for the COGO calculation.
Page To change to another page on this panel.
Description of fields
Field Option Description
From point Selectable list The backsight point.
At point Selectable list The point of intersection of the backsight
and f
o
resight direction.
To point Selectable list The foresight point.
Next step
Calcula
te calculates the result and accesses COGO Angle, Results page.
Key Description
OK To accept changes and return to the Input page.
Page To change to another page on this panel.
Access
COGO Angle,
Input page
COGO Angle,
R
esult
s page
522 COGO
