Next step
IF THEN
a traverse is to be created or selec-
ted
hig
hlight the relevant option and
press OK.
Traverse is to be configured Fn Content. Refer to "58.6 Configur-
ing Traverse".
58.3 Creating/Editing a Traverse
•
In T
raverse
, select Create a new traverse. Press OK.
•
In Manage Traverses, press New or Edit.
Key Description
OK To store the settings.
Fn Settings T
o configure the Traverse app. Refer to "58.6 Configuring
Traverse".
Description of fields
Field Option Description
Traverse ID Editable field The ID of the traverse.
Description Editable field A line for a detailed description of the tra-
ver
se, for example, work to be performed.
Optional.
Operator Editable field The name of the person who is creating the
traverse. Optional.
Date Display only Available in the Edit Traverse panel.
The date of when the traverse was created.
Time Display only Available in the Edit Traverse panel.
The time of when the traverse was created.
Status Available in the Edit Traverse panel.
Open The traverse is not closed in position.
Position
closed
The traverse has been closed in position on a
control point.
Posn &
angle closed
The traverse has been closed both in posi-
tion and angularly.
Access
New Traverse/
Edit Traverse
950 T
raverse
