Description of metadata
Metadata Description
- The point ID of the measured target points.
Out of limit The Out of limit indicates that the delta value of either
me
asured horizontal angle, distance or height exceeds the
calculation limit.
Unavailable for Orientate to object.
Use Indicates if and how a target point is used in the setup cal-
culation. Choices are 3D, 2D, 1D and No.
Hz diff Difference between calculated and measured horizontal
angle for the target points. If a target point does not have
coordinates, ----- are displayed. Differences exceeding the
defined limit are indicated by Out of limit.
Distance
diff
Difference between calculated and measured distance from
the setup to the target points. If a target point does not
have coordinates, ----- are displayed. Differences exceeding
the defined limit are indicated by Out of limit.
Height diff Difference between the known control point height and the
measured height of the target point. If a target point does
not have a height coordinate, ----- are displayed. Differences
exceeding the defined limit are indicated by Out of limit.
Easting diff Difference between control point and measured point, calcu-
lated from new setup coordinates.
Northing
diff
Difference between control point and measured point, calcu-
lated from new setup coordinates.
Next step
Page
changes to the 3D viewer page.
50.8 Finding a Target Point
The Fin
d Target panel can be accessed, to guide the prism to the selected tar-
ge
t point.
The panel is only available if the Stakeout app is available on the instrument.
The functionality of this panel is similar to a stakeout routine and is intended
to help find hidden survey bench marks or base points.
Press Fn Find
in Measure Target once enough data is available to calculate
roughly the new orientation.
This panel is similar to the St
ake Points,
page and is configured through
the St
ake Points settings. Refer to "Stake Points,page" for a detailed descrip-
tion of this panel.
Description
Access
Find Target
892 Setup - TS
