2-82 Printer Service Manual
5057-XXX
Go Back
Previous
Next
10
Check the transfer belt cleaning assembly for proper
installation or damage.
Remove the transfer belt cleaning assembly. See
“Transfer belt cleaning assembly removal” on
page 4-17.
Check for damage. The most likely damage (B,C) Is shown
in the following images.
Undamaged:
Damaged:
Is the transfer belt cleaning assembly damaged?
Replace the
transfer belt
cleaning
assembly. See
“Transfer belt
cleaning
assembly
removal” on
page 4-17.
Go to the next
step.
Step Check Yes No
