MOTOR TESTS
The tests in this group allow you to test specific motors, and on some motors run them forward or reverse.
To run the MOTOR TESTS:
1. Select MOTOR TESTS from the Diagnostics Menu.
2. Select the test to run.
C Channel (925.02)
K Channel (925.03)
Dev Unit Reset See “Dev Unit Reset” on page 3-19.
Y Channel
M Channel
C Channel
K Channel
ENGINE ADJUST See “ENGINE ADJUST” on page 3-20.
PH Adjust (registration)
PRO-CON
RegCon Adjust
Booklet Fold Adj
Finisher Config
Booklet Fold Adjust See “Booklet Fold Adjust” on page 3-23.
Booklet Tamper Shift Adj
Booklet Compile Position
Booklet 2-sheet
Booklet 15-sheet
Booklet Fold Pos Fine Adj
Booklet Staple Pos Fine Adj
Finisher Config See “Finisher Config” on page 3-23
Exit Diagnostics Menu See “Exiting Diagnostics” on page 3-23.
The following Finisher Motor Tests are available:
• Motor (entrance/paddle) • Stacker bin lift motor
• Motor (buffer/transport) • Booklet end guide drive motor
• Motor (exit) • Booklet paddle drive motor
• Fin diverter solenoid • Booklet front tamper motor
• Sub paddle solenoid • Booklet rear tamper motor
• Media eject clutch • Booklet folding/exit drive motor
• Media eject clamp motor • Booklet media entrance drive motor
• Media eject motor • Booklet transport motor
• Fin Buffer solenoid • Booklet knife solenoid
• Punch carriage shift motor • Booklet bin media transport motor
• Punch unit motor • Bridge unit diverter gate solenoid
• Front tamper motor • De-curler clutch
• Rear tamper motor • Bridge unit transport drive motor
• Stapler carriage motor • Booklet diverter gate solenoid
• Stapler unit motor • Booklet stapler motor
• • Bridge unit bin media exit solenoid
