Rear cover assembly removal
Note: Remove the blind cover (A) if the printer is equipped with a 1TM, 3TM, or a TTM.
1. Remove all connectors and power cords from the rear of the machine.
2. Remove the four screws securing the rear cover assembly (B) to the machine.
3. Remove the rear cover assembly (B).
B
A
Connectors
