Printer front door assembly removal
1. Open the printer front door assembly.
2. Press the tab, and rotate the two flexible supports (A) 90°, and pull from the machine.
3. Remove the two flexible supports (A).
4. Remove the two screws securing the two brackets (B) to the printer front door assembly (C).
5. Remove the two brackets (B).
6. Remove the printer front door assembly (C).
B
ab
A
C
T
