Lexmark C935 User Manual

Diagnostic information 2-107
5057-XXX
Go Back
Previous
Next
924.02 Cyan PC smartchip communication error
924.03 Black PC smartchip communication error
Step Check Yes No
1 Check the C PC cartridge for proper installation.
Is the above component properly installed?
Go to step 2. Reinstall the C PC
drum.
2
Install the C PC drum in one of the other three PC locations.
Ensure that all PC drum slots contain a PC drum. Perform a
POR.
Does the error remain or follow the problematic cartridge?
Replace the
problematic PC
drum with a new
one.
Go to step 3.
3
Check the appropriate smartchip socket, located on the
developer interlock plate assembly for proper connection.
is the above component properly connected?
Go to Step 4 Replace the
connection.
4
Check the appropriate smartchip socket, located on the
developer interlock plate assembly for wear or damage.
Is the above component free from damage?
Go to step 5. Replace the
developer
interlock plate
assembly. Go to
“Developer
interlock plate
assembly
removal” on
page 4-48.
5
Perform a POR.
Does the error occur when the power is turned off/on?
Replace the upper
printer engine card
assembly. Go to
Go to “Upper
printer engine
card assembly
removal” on
page 4-90
Problem solved.
Step Check Yes No
1 Check the KPC cartridge for proper installation.
Is the above component properly installed?
Go to step 2. Reinstall the K PC
drum.
2
Install the K PC drum in one of the other three PC locations.
Ensure that all PC drum slots contain a PC drum. Perform a
POR.
Does the error remain or follow the problematic cartridge?
Replace the
problematic PC
drum with a new
one.
Go to step 3.
3
Check the appropriate smartchip socket, located on the
developer interlock plate assembly for proper connection.
is the above component properly connected?
Go to Step 4 Replace the
connection.
4
Check the appropriate smartchip socket, located on the
developer interlock plate assembly for wear or damage.
Is the above component free from damage?
Go to step 5. Replace the
developer
interlock plate
assembly. Go to
“Developer
interlock plate
assembly
removal” on
page 4-48.

Lexmark C935 Specifications

General

Duplex printing	Yes
Print technology	Laser
Time to first page (black, normal)	5 s
Time to first page (color, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Print speed (color, normal quality, A4/US Letter)	40 ppm
PCL fonts	86
Printer fonts	PCL, PostScript, PPDS
Maximum duty cycle	200000 pages per month
Number of PostScript fonts	158
Number of print cartridges	4
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Maximum internal memory	1 MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	55 dB
Total input capacity	1140 sheets
Total output capacity	400 sheets
Internal modem	No
Networking features	Ethernet/Fast Ethernet/Gigabit Ethernet
Compatible operating systems	Apple Mac OS X Apple Mac OS 9.x Apple Mac OS X (10.4) Red Flag Linux Desktop 4.0, 5.0 Linpus Linux Desktop 9.2, 9.3 Red Hat Enterprise Linux WS 3.0, 4.0, 5.0 SUSE Linux Enterprise Server 8.0, 9.0, 10.0 Debian GNU/Linux 3.1 Linspire Linux 5.0 SUSE Linux 10.0, 10.1, 10.2 Microsoft Windows 2000 Microsoft Windows NT (4.00/4.00 Server) Microsoft Windows XP Microsoft Windows Server 2003 Microsoft Windows XP x64 Microsoft Windows Server 2003 + Terminal Server Microsoft Windows 2000 Server + Terminal Services Microsoft Windows Server 2003 x64 Microsoft Windows Server 2003 x64 + Terminal Services Microsoft Windows Vista Microsoft Windows Vista x64 Novell Open Enterprise Server + NDS, iPrint Novell NetWare 3.2, 4.2 Novell NetWare 4.2, 5.x & 6.x Novell NetWare 5.x, 6.x + iPrint IBM iSeries / IBM AS/400 + OS/400 V3R1 Sun Solaris SPARC 7, 8, 9, 10 HP-UX 11.00, 11.1 IBM AIX 5.1, 5.2, 5.3 Sun Solaris x86 10
Supported network protocols (IPv4)	TCP/IP IPv4, IPX/SPX, AppleTalk, LexLink (DLC), TCP/IP IPv6
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	8 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	1241 x 975 x 710 mm
