Switch (media size)
The following table gives on/off states of the switches on the switch (media size), corresponding to the media
sizes of the media tray assembly.
Note: The switches (media size) are denoted by “S/W1” and “S/W3” respectively from the left side.
Media Size
Analog switch
S/W1 S/W3
No Tray Off Off
B5L/7.25” x 10.5”L Off On
8.5” x 11”L On Off
A4L On On
