Lexmark X792 - Page 396

To Next Page

To Previous Page

4-86 Service Manual

7562

Go Back

3. Push in to open the cable clip (B) behind the system board shield.

4. Feed the cable through the slot in the system board cage and the clip.

5. Remove the two screws (C).

C (10B1580)
