Lexmark X792 - Rear Upper Cover Removal

To Next Page

To Previous Page

Repair information 4-25

7562

Go Back

Rear upper cover removal

See “Left and rear covers” on page 7-5 for the part number.

1. Open the system board shield door, and remove the three screws (A).

A (88A0213)
